METALLIC
CONDUIT & FITTINGS
80
ww w.flexicon.uk.comFittings
STANDARD
EMC
SCREEN
ENHANCED
EMC
SCREEN
SUPER
EMC
SCREEN
LTPB16-M16-C
LTPB16-M20-C
LTPB20-M20-C
LTPB25-M25-C
LTPB32-M32-C
LTPB40-M40-C
LTPB50-M50-C*
LTPB16-M16-S
LTPB16-M20-S
LTPB20-M20-S
LTPB25-M25-S
LTPB32-M32-S
LTPB40-M40-S
LTPB50-M50-S*
metric thread
part number
metric thread
part number
outside dia (mm)
inside dia (mm)
min inside bend
radius (mm)
part number
reel length (m)
LT P B R D
nominal size (mm)
LTPBRD16
25
19.3
12.6
45
LTPBRD20
25
22.6
16.0
65
LTPBRD25
25
27.9
21.0 100
LTPBRD32
25
34.6
26.5 135
LTPBRD40
10
43.3
35.4 175
LTPBRD50*+
10
49.3
40.4 230
•
Add reel length eg: LTPBRD20B-25M for 25m reel
* Indicates parts made to order on request and
may be subject to MOQ and lead time
+ Double interlock section
• Available on request:
- longer lengths-
45° available in sizes 16-50mm
-
cut lengths and assemblies
-
additional sizes
-
full copies of independent test report
confirming screening effectiveness
conduit
thread size
fitting type
How to read the fittings code
LTPB20-M20-M
LTPBRD
Construction:
Galvanised steel, helically
wound, flexible conduit with thermoplastic
elastomer cover (same as LTPHC) and
stainless steel (grade 316) overbraid.
Typical Applications:
Very arduous
industrial environments such as steel
works.
BS EN IEC 61386
C
C-S
external thread
nickel plated brass
Multipart compression fitting
including elastomeric seal. Can
be used for knockout. Braid is
locked between inner and outer
compression nuts.
swivel external thread
nickel plated brass
Multipart compression fitting
including elastomeric seal can be
used for knockouts or threaded
entries. Braid is locked between
inner and outer compression
nuts.
IP68
IP67
IP66
IP65
IP54
IP40
IP69
I
I
I
I
I
I
I
IP68
IP67
IP66
IP65
IP54
IP40
IP69
I
I
I
I
I
I
I
16
16
20
25
32
40
50
Ordering Notes
Standards
Conduit
LTPBRD
system
galvanised steel core,
thermoplastic elastomer
coated and stainless
steel overbraid
REACh
