Flexicon Product and Solutions Guide

79 / 114

79
• High mechanical strength
• Highly flexible
• IP rating: IP40
• High abrasion resistance
• Resists hot metal swarf and splashes
• Provides EMC screening
(FB)
(FUSSB)
• Temperature range -100˚C to +300˚C
• Inherently Low Fire Hazard (LFH)
• Fully compliant to LUL Std 1-085. (Cert No. 296)
• Nickel plated brass fittings
properties
12 FB12-P
16 FB16-P
20 FB20-P
25 FB25-P
32 FB32-P
40 FB40-P
51 FB50-P
part number hole size (mm) metric threadpart number plated steelpart numberstainless steelpart number
FCC12 FCC12-SS*
FCC16 FCC16-SS
FCC16 FCC16-SS
FCC20 FCC20-SS
FCC25 FCC25-SS
FCC32 FCC32-SS
FCC40 FCC40-SS
FCC50 FCC50-SS*
nominal size (mm)
S-M16
S-M16
S-M20
S-M20
S-M25
S-M32
S-M40
S-M50
metric threadsteelpart number metric threadbrasspart number metric threadEMCpart number
B-M16
B-M16
B-M20
B-M20
B-M25
B-M32
B-M40
B-M50
B-M20-EMC
B-M20-EMC
B-M25-EMC
B-M32-EMC
B-M40-EMC
BM90-16M
BM90-16M
BM90-20M
BM90-20M
BM90-25M
BM90-32M
BM90-40M
BM90-50M
P locknuts 90° elbow FCC
plain hole
connector
nickel plated brass
Two part fitting comprising
shell and body without
thread. The body is fitted
through the opposite side
of the entry to the conduit
and acts as a locking
device also providing a
smooth entry bush.
internal and external
threaded nickel plated
brass elbow
90˚ elbow which can be screwed
onto external threaded fittings.
galvanised steel and
nickel plated brass
locknuts
Hexagonal locknut to secure
fitting. EMC locknuts have
raised corners to ensure good
continuity.
plated steel P clip with
pvc liner, stainless steel
P clips
P clip to support and secure
conduit.
IP68 IP67 IP66 IP65 IP54 IP40 IP69
FB FUSSB
EMC Screening Performance
12
16
16
20
25
32
40
50
Ordering Notes
