METALLIC
CONDUIT & FITTINGS
82
FPRSS system corrugated
nylon, stainless steel overbraid
FPRTC system corrugated
nylon, tinned copper overbraid
STANDARD
LOW FIRE
HAZARD
EXTRA
LOW FIRE
HAZARD
INHERENT
LOW FIRE
HAZARD
STANDARD
EMC
SCREEN
ENHANCED
EMC
SCREEN
STANDARDEMC
SCREEN
ENHANCEDEMC
SCREEN
SUPER
EMC
SCREEN
STANDARD
LOW FIRE
HAZARD
EXTRA
LOW FIRE
HAZARD
INHERENT
LOW FIRE
HAZARD
BC16-M16-C
BC21-M20-C
BC28-M25-C
BC34-M32-C
BC42-M40-C
BC54-M50-C*
BC16-M16-S
BC21-M20-S
BC28-M25-S
BC34-M32-S
BC42-M40-S
BC54-M50-S*
metric threadpart number metric threadpart number
BC16-PG11-S
BC21-PG16-S
BC28-PG21-S
BC34-PG29-S
PG threadpart number outside dia (mm)min inside dia (mm)min inside bendradius (mm) part number F P R S S part number F P R T C part number F P I S S part number F P I H S S nominal size (mm)
16
20
25
32
40
50
Fittings
FPRSS
FPISS
FPRTC
FPIHSS
Construction: Standard weight,
corrugated nylon (PA12), with
stainless steel (316) overbraid.
Typical Applications: Moving
machinery where low
temperatures, abrasion and
impacts occur.
Construction: Standard weight,
extra low fire hazard,
corrugated nylon (PA6), with
tinned copper overbraid.
Typical Applications: Inside
railway carriages where
screening is required.
Construction: Standard weight,
extra low fire hazard, corrugated
nylon (PA6), with stainless steel
(316) overbraid.
Typical Applications:
Metro rail stations for anti-
vandal.
Construction: Heavy weight,
corrugated nylon (PA12), with
stainless steel (316) overbraid.
Typical Applications: Under
railway carriages where low
temperatures, abrasion, impact
and regular movement occurs.
C
fixed external
thread nickel
plated brass
Multipart compression
fitting including conduit
retention clip and
elastomeric seal. Can be
used with knockouts.
Braid is locked between
inner and outer
compression nuts.
C-S
swivel external
thread nickel
plated brass
Multipart compression
fitting including conduit
retention clip and
elastomeric seal. Can be
used for knockouts and
threaded entries. Braid is
locked between inner and
outer compression nuts.
IP68 IP67 IP66 IP65 IP54 IP40 IP69 IP68 IP67 IP66 IP65 IP54 IP40 IP69
Ordering Notes
BS EN IEC 61386
Note: refer to conduit properties for applicable standards
* Indicates parts made to order on request and
may be subject to MOQ and lead time
• Available on request:
- cut lengths and assemblies
- additional sizes
- full copies of independent test report
- confirming screening effectiveness
conduit
thread size
fitting type
How to read the fittings code
BC21-M20-C
FPRSS16-50M FPRTC16-50M* FPISS16-50M* FPIHSS16-50M 17.3 11.5 35
FPRSS21-50M FPRTC21-50M* FPISS21-50M* FPIHSS21-50M 22.7 15.0 45
FPRSS28-50M FPRTC28-50M* FPISS28-50M* FPIHSS28-50M 30.0 21.3 50
FPRSS34-50M FPRTC34-50M* FPISS34-25M* FPIHSS34-25M 36.0 27.6 60
FPRSS42-25M* FPRTC42-25M* FPISS42-25M* FPIHSS42-25M* 44.0 35.5 70
FPRSS54-25M* FPRTC54-25M* FPISS54-25M* FPIHSS54-25M* 56.0 47.2 80
Standards
Conduit
REACh
