Construction: Nylon (PA66) moulded fitting with swivel
metal thread. External and internal metallic threads are
made from nickel plated brass and incorporate an
internal elastomeric seal. Colour black, grey on request*.
FPAX system brass threaded
• NPB = Nickel Plated Brass
de to order on request
• Available on request:
- colour grey, other threads
- for brass locknuts and sealing washers see
accessories, page 86
- EMC braid clamp version, see page 85
NON-METALLIC
CONDUIT & FITTINGS
90° elbow swivel brass
internal thread
Fast fit, swivel, 90 degree elbow, nickel
plated brass internal threaded fitting with
additional conduit seal.
IP68 IP67 IP66 IP65 IP54 IP40 IP69 I I I I I I I
45° elbow swivel brass
external thread
Fast fit, swivel, 45 degree elbow, nickel
plated brass external threaded fitting with
additional conduit seal. Suitable for
knockouts or threaded entries.
45° elbow swivel brass
internal thread
Fast fit, swivel, 45 degree elbow, nickel
plated brass internal threaded fitting
with additional conduit seal.
FPAX90 FPAX45 FPAX45
NPB Int Metric
FPAX13-BFM16-90
FPAX16-BFM16-90
FPAX16-BFM20-90
FPAX21-BFM20-90
FPAX28-BFM25-90
FPAX34-BFM32-90
FPAX42-BFM50-90
FPAX54-BFM50-90
NPB Int PG
FPAX13-BFPG9-90*
FPAX16-BFPG11-90*
FPAX16-BFPG16-90*
FPAX21-BFPG16-90*
FPAX28-BFPG21-90*
FPAX34-BFPG29-90*
FPAX42-BFPG36-90*
NPB Ext Metric
FPAX16-BM16-45
FPAX16-BM20-45
FPAX21-BM20-45
FPAX28-BM25-45
FPAX34-BM32-45
FPAX42-BM40-45
FPAX42-BM50-45
FPAX54-BM50-45
FPAX54-BM63-45
NPB Ext PG
FPAX16-BPG13-45
FPAX16-BPG16-45
FPAX21-BPG13-45
FPAX21-BPG16-45
FPAX28-BPG21-45
FPAX34-BPG29-45
FPAX42-BPG36-45
FPAX54-BPG48-45*
NPB Int Metric
FPAX16-BFM20-45
FPAX21-BFM20-45
FPAX28-BFM25-45
FPAX34-BFM32-45
FPAX42-BFM50-45
FPAX54-BFM50-45
NPB Int PG
FPAX16-BFPG16-45*
FPAX21-BFPG16-45*
FPAX28-BFPG21-45*
FPAX34-BFPG29-45*
FPAX42-BFPG36-45*
OD mm nominal size (mm) european (NW) sizes
IP68 IP67 IP66 IP65 IP54 IP40 IP69 I I I I I I I IP68 IP67 IP66 IP65 IP54 IP40 IP69 I I I I I I I
STANDARD
LOW FIRE
HAZARD
EXTRA
LOW FIRE
HAZARD
INHERENT
LOW FIRE
HAZARD IP68 IP67 IP66 IP65 IP54 IP40 IP69 IP68 IP67 IP 6 IP65 IP54 IP40 IP69 IP68 IP67 IP 6 IP65 IP54 IP40 IP69 IP68 IP67 IP 6 IP65 IP54 IP40 IP69
10
10
11
13
13
13
16
16
16
16
18
18
20
21
21
21
25
28
28
34
34
42
42
54
54
67
10.0
11.5
13.0
15.8
18.5
20.0
21.2
25.0
28.5
34.5
42.5
54.5
67.0
7
7
8
10
10
10
12
12
12
12
14
14
17
17
17
23
23
29
29
36
36
48
48
56
