Fast fit
•
Supplied with additional conduit seal and retained
face seal
•
Face seal details:
–
Nylon and Brass external threads supplied
with Polyester elastomer washer
–
UNEF and Flange supplied with O-ring
•
IP rating: IP66 + IP67 + IP68 (2 bar) + IP69
•
Vibration and shock tested to EN61373 Cat 2
•
Tamper resistant
•
Can be removed using a screwdriver
•
All round teeth give high pull off strength
70kg with FPAH21
•
Both 90˚ and 45˚ elbows incorporate swept bore
to facilitate cable installation and protect cables
when installed
•
Suitable for fine and coarse pitch conduits
•
Temperature range -50˚C to +135˚C
•
Metric nylon threads supplied complete
with locknuts
•
Swivel UNEF threads allow assembly to
military style electrical connectors without
twisting of cables and includes sealing
‘O’ ring face seal
•
Low Fire Hazard (LFH), see page 102
•
Halogen, sulphur and phosphorus free
properties
OD mm
nominal size (mm)
NPB Ext Metric
FPAX13-BM16
FPAX16-BM16
FPAX16-BM20
FPAX21-BM20
FPAX28-BM25
FPAX34-BM32
FPAX42-BM40
FPAX42-BM50
FPAX54-BM50
FPAX54-BM63
NPB Ext PG
FPAX13-BPG9
FPAX16-BPG9
FPAX16-BPG11
FPAX21-BPG13
FPAX21-BPG16
FPAX28-BPG21
FPAX34-BPG29
FPAX42-BPG36
FPAX54-BPG48*
NPB Int Metric
FPAX13-BFM16
FPAX16-BFM16
FPAX16-BFM20
FPAX21-BFM20
FPAX28-BFM25
FPAX34-BFM32
FPAX42-BFM40
FPAX54-BFM50
NPB Int PG
FPAX13-BFPG9*
FPAX16-BFPG11*
FPAX16-BFPG16*
FPAX21-BFPG16*
FPAX28-BFPG21*
FPAX34-BFPG29*
FPAX42-BFPG36*
european (NW) sizes
straight swivel brass external
thread
Fast fit, swivel, nickel plated brass
external threaded fitting with additional
conduit seal. Suitable for knockouts or
threaded entries.
straight swivel brass internal
thread
Fast fit, swivel, nickel plated brass internal
threaded fitting with additional conduit seal.
90° elbow swivel brass
external thread
Fast fit, swivel, 90 degree elbow, nickel
plated brass external threaded fitting
with additional conduit seal. Suitable for
knockouts or threaded entries.
FPAX
FPAX
FPAX90
IP68
IP67
IP66
IP65
IP54
IP69
I
I
I
I
I
I
IP68
IP67
IP66
IP65
IP54
IP40
IP69
I
I
I
I
I
I
I
IP68
IP67
IP66
IP65
IP54
IP40
IP69
I
I
I
I
I
I
I
10
10
11
13
13
13
16
16
16
16
18
18
20
21
21
21
25
28
28
34
34
42
42
54
54
67
7
7
8
10
10
10
12
12
12
12
14
14
17
17
17
23
23
29
29
36
36
48
48
56
10.0
11.5
13.0
15.8
18.5
20.0
21.2
25.0
28.5
34.5
42.5
54.5
67.0
NPB Ext Metric
FPAX13-BM16-90
FPAX16-BM16-90
FPAX16-BM20-90
FPAX21-BM20-90
FPAX28-BM25-90
FPAX34-BM32-90
FPAX42-BM40-90
FPAX42-BM50-90
FPAX54-BM50-90
FPAX54-BM63-90
NPB Ext PG
FPAX13-BPG9-90
FPAX16-BPG9-90
FPAX16-BPG11-90
FPAX21-BPG13-90
FPAX21-BPG16-90
FPAX28-BPG21-90
FPAX34-BPG29-90
FPAX42-BPG36-90
FPAX54-BPG48-90*
BS EN IEC 61386
REACh
