Fitting to reduce or blank
off any outlets.
Reducer/
Stop Plug
T piece with inspection lid
Fast fit T piece with inspection lid
and additional seals for enhanced
IP rating.
FPAX
IP68
IP67
IP66
IP65
IP54
IP40
IP69
I
I
I
I
I
I
I
Divider
Fast fit reducing divider with additional seals
for enhanced IP ratings
FPAX
IP68
IP67
IP66
IP65
IP54
IP40
IP69
I
I
I
I
I
I
I
IP68
IP67
IP66
IP65
IP54
IP40
IP69
I
I
I
I
I
I
I
16
21
28
34
13
16
21
28
12
17
23
29
36
•
Fast fit
•
IP rating: FPA IP66
FPAX IP66 + IP67 + IP68 (2 bar)
FPAX Divider IP66 + IP67 + IP68 (2 bar) +IP69
•
Maintains all the benefits of FPA and FPAX fittings
•
Vibration and shock tested to EN61373 Cat 2
•
Tamper resistant
•
All round teeth give high pull off strength
•
Low Fire Hazard (LFH), see page 102
•
Halogen, sulphur & phosphorous free
•
Inspection lid facilitates pull through of cables easing
installation on the T-piece
•
Rounded internal corners protect cable insulation during
installation and use
•
Incorporates mounting lugs to aid secure fixing
properties
Conduit In
Conduit Out x 2 for divider
european (NW) sizes
R
SP
FPAX16-13-13
FPAX21-16-16
FPAX28-21-21
FPAX34-28-28
FPAX13-R16
FPAX16-R21
SP-R21
FPAX21-R28
FPAX16-R28
SP-R28
FPAX28-R34
FPAX21-R34
FPAX16-R34
FPAX34-R42
FPAX28-R42
FPAX21-R42
FPAX16T
FPAX21T
FPAX28T
FPAX34T
FPAX42T
