NON-METALLIC
CONDUIT & FITTINGS
Ordering Notes
Fittings
FPY, FPYS, FPYL,
FPYLS system
corrugated flexible conduit
Ordering Notes
Conduit
F = fine pitch C = coarse pitch
outside dia (mm) outside dia (mm) outside dia (mm) outside dia (mm) inside dia (mm) inside dia (mm) inside dia (mm) inside dia (mm) min inside bendradius (mm) min inside bendradius (mm) min inside bendradius (mm) min inside bendradius (mm) part number part number part number part number reel length (m) reel length (m) reel length (m) reel length (m) FPY FPYS FPYL FPYLS
FPY FPYS FPYL FPYLS
Construction: Nylon (PA6)
corrugated flexible conduit.
Colour black.
Typical Applications:
Automotive
Construction: Slit nylon
(PA6) corrugated flexible
conduit. Colour black.
Typical Applications:
Automotive looms,
harnesses and retrofit.
Construction: Nylon (PA6)
corrugated flexible conduit.
Colour black.
Typical Applications:
Lightweight automotive.
Construction: Slit, light
weight nylon (PA6)
corrugated flexible conduit.
Colour black.
Typical Applications:
Lightweight automotive
looms, harnesses and retrofit.
• Highly flexible and high fatigue life
• High impact strength and recovers if crushed
• Temperature range -40˚C to +120˚C
• Highly resistant to solvents and oils
• Self extinguishing (FPY and FPYS)
• Halogen, sulphur and phosphorus free
properties
nominal size (mm)pitch european (NW) sizes
upplied complete with locknuts
• Available on request:
- reduced outlet T pieces
- other colours
- PG threads
* FPYL & FPYLS are made to order on
request and maybe subject to MOQ
and lead times.
FPYLS8B* 100 10.0 6.5 15
FPYLS10B*100 11.5 8.5 20
FPYLS12B*100 13.0 10.1 25
FPYLS16B*100 16.1 13.0 35
FPYLS18B*100 18.5 14.4 35
FPYLS20B*100 21.2 17.1 40
FPYLS25B*100 25.4 21.6 45
FPYLS28B* 50 28.5 23.2 45
FPYLS32B* 50 34.5 28.5 55
FPYLS40B* 50 42.5 35.9 65
FPYLS50B* 50 54.5 47.6 80
FPYS8B 50 10.0 6.5 15
FPYS10B 50 11.5 8.5 20
FPYS12B 50 13.0 10.0 25
FPYS16B 50 16.1 12.8 35
FPYS18B 50 18.5 14.2 35
FPYS20B 50 21.2 16.9 40
FPYS25B 50 25.4 21.4 45
FPYS28B 50 28.5 23.0 45
FPYS32B 25 34.5 28.3 55
FPYS40B 25 42.5 35.7 65
FPYS50B 25 54.5 47.4 80
FPYL8B* 100 10.0 6.5 15
FPYL10B*100 11.5 8.5 20
FPYL12B*100 13.0 10.1 25
FPYL16B*100 16.1 13.0 35
FPYL18B*100 18.5 14.4 35
FPYL20B*100 21.2 17.1 40
FPYL25B*100 25.4 21.6 45
FPYL28B* 50 28.5 23.2 45
FPYL32B* 50 34.5 28.5 55
FPYL40B* 50 42.5 35.9 65
FPYL50B* 50 54.5 47.6 80
FPY6B 100 7.1 4.8 10
FPY8B 50 10.0 6.5 15
FPY10B 50 11.5 8.5 20
FPY12B 50 13.0 10.0 25
FPY16B 50 16.1 12.8 35
FPY18B 50 18.5 14.2 35
FPY20B 50 21.2 16.9 40
FPY25B 50 25.4 21.4 45
FPY28B 50 28.5 23.0 45
FPY32B 25 34.5 28.3 55
FPY40B 25 42.5 35.7 65
FPY50B 25 54.5 47.4 80
