Standards
Technical Drawing
•
Highly flexible
•
Accepts torsional movement
•
Vibration and shock tested to EN61373 Cat 2
•
IP rating: IP65
•
Temperature range
-5˚C to +70˚C (FPCB - black)
-20˚C to +70˚C (FPCG - grey)
-20˚C to +70˚C (FPCGN - green)
-20˚C to +90˚C (FPCBU - blue)
-5˚C to +70˚C (LTS - silver grey)
•
FPCB (black) is UV resistant
•
FPCGN (green) is oil resistant
•
FPCBU (blue) is high temperature
•
Self extinguishing
•
Metric threads supplied complete with locknuts
•
FPCG, FPCGN, FPCBU and FPCURB are UL
recognised to UL1696 for use in US and Canada
•
LTS (silver grey) is smooth outer and smooth bore
properties
outside dia (mm)
inside dia (mm)
reel length (m)
nominal size (mm)
BS EN IEC 61386
* refer to conduit properties for applicable standards
REACh
MPC90-16-M16
MPC90-16-M20
MPC90-20-M20
MPC90-25-M25
MPC90-32-M32
MPC90-40-M40
MPC90-50-M50
MPC90-63-M63
metric thread
part number
MPC45-16-M20
MPC45-20-M20
MPC45-25-M25
MPC45-32-M32
MPC45-16-050
MPC45-20-050
MPC45-25-075
MPC45-32-100
LTS16SG-50M
LTS20SG-50M
LTS25SG-50M
LTS32SG-50M
metric thread
part number
NPT
part number
part number
MPC90-16-PG11
MPC90-16-PG13
MPC90-20-PG16
MPC90-25-PG21
MPC90-32-PG29
MPC90-40-PG36
MPC90-16-050
MPC90-20-050
MPC90-25-075
MPC90-32-100
MPC90-40-125
MPC90-50-150
MPC90-63-200
PG thread
part number
NPT
part number
90° elbow nylon compression fitting
external thread
2 part compression, 90 degree elbow fitting with internal
spigot and all round external teeth to grip conduit.
Available in black or grey (RAL 7001).
45° elbow nylon compression fitting
external thread
2 part compression, 45 degree elbow fitting with
internal spigot and all round external teeth to grip
conduit. Available in black or grey (RAL 7001).
MPC90
MPC45
IP68
IP67
IP66
IP65
IP54
IP40
IP69
IP68
IP67
IP66
IP65
IP54
IP40
IP69
12
16
16
20
25
30
32
40
50
63
50
16.5
12
50
21.0
16
50
27.5
22
50
33.5
28
smooth bore liquid
tight sheathing
PVC, silver grey sheathing
ideal for routing cables within
machines. IP66 rating when
used with MPC fittings.
LTS
