Fast fit
•
Supplied with additional conduit seal & retained
face seal
•
Face seal details:
–
Nylon and Brass external threads supplied
with Polyester elastomer washer
–
UNEF and Flange supplied with O-ring
•
IP rating:
for conduit & fitting IP66 + IP67 +
IP68 (2 bar) + IP69
for cable gland: IP68 (10 bar)+IP69
•
Vibration and shock tested to EN61373 Cat 2
•
Tamper resistant
•
Both 90˚ and 45˚ elbows incorporate swept
bore to facilitate cable installation and protect
cables when installed
•
Can be removed using a screwdriver
•
All round teeth give high pull off strength
70kg with FPAH21
•
Both 90˚ and 45˚ elbows incorporate swept
bore to facilitate cable installation and protect
cables when installed
•
Suitable for fine and coarse pitch conduits
•
Temperature range:
conduit fitting: -50˚C to +135˚C
cable gland: -40˚C to +100˚C static
-20˚C to +100˚C dynamic
•
Low Fire Hazard (LFH), see page 102
•
Halogen, sulphur and phosphorus free
•
Refer to accessories for clamping range
page 87
properties
cable gland
Fast fit, swivel, nickel plated brass external
threaded cable gland fitting with additional conduit
seal. Suitable for knockouts or threaded entries.
cable gland
Fast fit, swivel, 45 degree elbow,
nickel plated brass external
threaded cable gland fitting with
additional conduit seal. Suitable for
knockouts or threaded entries.
cable gland
Fast fit, swivel, 90 degree elbow, nickel
plated brass external threaded cable gland
fitting with additional conduit seal. Suitable
for knockouts or threaded entries.
FPAX45
FPAX90
FPAX
NPB Metric
FPAX16-BM20-CG-45
FPAX21-BM20-CG-45
FPAX28-BM25-CG-45
FPAX34-BM32-CG-45
FPAX42-BM40-CG-45
FPAX54-BM50-CG-45*
NPB Metric
FPAX13-BM16-CG-90
FPAX16-BM16-CG-90
FPAX16-BM20-CG-90
FPAX21-BM20-CG-90
FPAX28-BM25-CG-90
FPAX34-BM32-CG-90
FPAX42-BM40-CG-90
FPAX54-BM50-CG-90*
NPB Metric
FPAX13-BM16-CG
FPAX16-BM16-CG
FPAX16-BM20-CG
FPAX21-BM20-CG
FPAX28-BM25-CG
FPAX34-BM32-CG
FPAX42-BM40-CG
FPAX54-BM50-CG*
NPB PG
FPAX16-BPG11-CG*
FPAX16-BPG16-CG*
FPAX21-BPG16-CG*
FPAX28-BPG21-CG*
FPAX34-BPG29-CG*
FPAX42-BPG36-CG*
nominal size (mm)
european (NW) sizes
OD mm
IP68
IP67
IP66
IP65
IP54
IP40
IP69
I
I
I
I
I
I
I
IP68
IP67
IP66
IP65
IP54
IP69
I
I
I
I
I
0
I
IP68
IP67
IP66
IP65
IP54
IP40
IP69
IP68
IP67
IP66
IP65
IP54
IP40
IP69
10
10
11
13
13
13
16
16
16
16
18
18
20
21
21
21
25
28
28
34
34
42
42
54
54
67
7
7
8
10
10
10
12
12
12
12
14
14
17
17
17
23
23
29
29
36
36
48
48
56
10.0
11.5
13.0
15.8
18.5
20.0
21.2
25.0
28.5
34.5
42.5
54.5
67.0
Standards
Technical Drawing
REACh
BS EN IEC 61386
