31 / 114
31
Standards
Technical Drawing
BS EN IEC 61386
REACh
Standards
properties
•
Fast fit
•
Supplied with additional conduit seal
and retained face seal
•
Face seal details:
–
Nylon and Brass external threads
supplied with Polyester elastomer
washer
–
UNEF and Flange supplied with
O-ring
•
IP rating:
IP66 + IP67 + IP68 (2 bar) + IP69
•
Vibration and shock tested to EN61373
Cat 2
•
Tamper resistant
•
Can be removed using a screwdriver
•
All round teeth give high pull off strength
70kg with FPAH21
•
Both 90˚ and 45˚ elbows incorporate
swept bore to facilitate cable installation
and protect cables when installed
•
Suitable for fine and coarse
pitch conduits
•
Temperature range -50˚C to +135˚C
•
Metric nylon threads supplied
complete with locknuts
•
Swivel UNEF threads allow assembly
to military style electrical connectors
without twisting of cables and
includes sealing ‘O’ ring face seal
•
Low Fire Hazard (LFH), see page 102
•
Halogen, sulphur and phosphorus free
OD mm
10
10
11
13
13
13
16
16
16
16
18
18
20
21
21
21
25
28
28
34
34
42
42
54
54
67
10.0
11.5
13.0
15.8
18.5
20.0
21.2
25.0
28.5
34.5
42.5
54.5
67.0
nominal size (mm)
Ext Metric
FPAX13-M16-90
FPAX16-M16-90
FPAX16-M20-90
FPAX21-M20-90
FPAX28-M25-90
FPAX34-M32-90
FPAX42-M40-90
FPAX42-M50-90
FPAX54-M50-90
FPAX54-M63-90
Ext PG
FPAX13-PG9-90
FPAX16-PG9-90
FPAX16-PG11-90
FPAX16-PG13-90
FPAX21-PG13-90
FPAX21-PG16-90
FPAX28-PG21-90
FPAX34-PG29-90
FPAX42-PG36-90
FPAX54-PG48-90
Ext NPT
FPAX16-050-90
FPAX21-050-90
FPAX28-075-90
FPAX34-100-90
FPAX42-125-90
FPAX42-150-90
FPAX54-150-90
FPAX54-200-90
Flange
FPAX16-FL-90
FPAX21-FL-90
FPAX28-FL-90
FPAX34-FL-90
FPAX42-FL-90
Thread
(
3
⁄
4
")
(1")
(1
3
⁄
16
")
(1")
(1
3
⁄
16
")
(1
3
⁄
8
")
(1
3
⁄
8
")
(1
7
⁄
16
")
(1
7
⁄
16
")
(2")
(2
1
⁄
4
")
(2")
(2
1
⁄
4
")
european (NW) sizes
7
7
8
10
10
10
12
12
12
12
14
14
17
17
17
23
23
29
29
36
36
48
48
56
Int UNEF
FPAX16-BU075-90
FPAX16-BU100-90
FPAX16-BU119-90
FPAX21-BU100-90
FPAX21-BU119-90
FPAX21-BU138-90
FPAX28-BU138-90
FPAX28-BU144-90
FPAX34-BU144-90
FPAX42-BU200-90
FPAX42-BU225-90
FPAX54-BU200-90
FPAX54-BU225-90
90° elbow external thread
Fast fit, external threaded 90 degree elbow fitting with
additional conduit seal. Suitable for knockouts.
90° elbow UNEF swivel internal
thread
Fast fit, 90 degree elbow fitting with nickel
plated brass swivel UNEF internal thread
for attachment to circular connectors with
additional conduit seal.
flange
Fast fit 90 degree elbow fitting with
nylon swivel flange with additional
conduit seal with 'O' ring face seal.
FPAX90
FPAX90
FPAX90
IP68
IP67
IP66
IP65
IP54
IP40
IP69
I
I
I
I
I
I
I
IP68
IP67
IP66
IP65
IP54
IP40
IP69
I
I
I
I
I
I
I
IP68
IP67
IP66
IP65
IP54
IP40
IP69
I
I
I
I
I
I
I
