ww w.flexicon.uk.comNON-METALLIC
CONDUIT & FITTINGS
Ordering Notes
Fittings
IP68
IP67
IP66
IP65
IP54
IP40
IP69
STANDARD
LOW FIRE
HAZARD
EXTRA
LOW FIRE
HAZARD
INHERENT
LOW FIRE
HAZARD
Construction:
Nylon (PA66) moulded fitting with nickel
plated brass swivel thread. Colour black or grey.
FPA
system
brass threaded
OD mm
nominal size (mm)
NPB Int Metric
FPA13-BFM16-90
FPA16-BFM16-90
FPA16-BFM20-90
FPA21-BFM20-90
FPA28-BFM25-90
FPA34-BFM32-90
FPA42-BFM50-90
FPA54-BFM50-90
NPB Int PG
FPA13-BFPG9-90*
FPA16-BFPG11-90*
FPA16-BFPG16-90*
FPA21-BFPG16-90*
FPA28-BFPG21-90*
FPA34-BFPG29-90*
FPA42-BFPG36-90*
NPB Ext Metric
FPA16-BM16-45
FPA16-BM20-45
FPA21-BM20-45
FPA28-BM25-45
FPA34-BM32-45
FPA42-BM40-45
FPA42-BM50-45
FPA54-BM50-45
FPA54-BM63-45
NPB Ext PG
FPA16-BPG13-45
FPA16-BPG16-45
FPA21-BPG13-45
FPA21-BPG16-45
FPA28-BPG21-45
FPA34-BPG29-45
FPA42-BPG36-45
FPA54-BPG48-45
NPB Int Metric
FPA16-BFM20-45
FPA21-BFM20-45
FPA28-BFM25-45
FPA34-BFM32-45
FPA42-BFM50-45
FPA54-BFM50-45
NPB Int PG
FPA16-BFPG16-45*
FPA21-BFPG16-45*
FPA28-BFPG21-45*
FPA34-BFPG29-45*
FPA42-BFPG36-45*
european (NW) sizes
90° elbow swivel brass
internal thread
One piece, fast fit, swivel, 90 degree
elbow, nickel plated brass internal
threaded fitting.
45° elbow swivel brass
external thread
One piece, fast fit, swivel, 45 degree
elbow, nickel plated brass external
threaded fitting. Suitable for knockouts or
threaded entries.
45° elbow swivel brass
internal thread
One piece, fast fit, swivel, 45 degree
elbow, nickel plated brass internal
threaded fitting.
FPA90
FPA45
FPA45
IP68
IP67
IP66
IP65
IP54
IP40
IP69
IP68
IP67
IP66
IP65
IP54
IP40
IP69
IP68
IP67
IP66
IP65
IP54
IP40
IP69
* Indicates parts made to order on request
• NPB = Nickel Plated Brass
•
Available on request:
-
colour grey, other threads
-
for brass locknuts and sealing washers
see accessories, page 86
-
EMC braid clamp version, see page 85
