24 / 114
Fittings
Ordering Notes
FPA
system
nylon
IP68
IP67
IP66
IP65
IP54
IP40
IP69
STANDARD
LOW FIRE
HAZARD
EXTRA
LOW FIRE
HAZARD
INHERENT
LOW FIRE
HAZARD
Construction:
Nylon (PA66) moulded fitting.
FPA
FPA
OD mm
10.0
11.5
13.0
15.8
18.5
20.0
21.2
25.0
28.5
34.5
42.5
54.5
67.0
straight UNEF
swivel internal thread
One piece, fast fit fitting with
nickel plated brass swivel UNEF
internal thread for attachment
to circular connectors.
IP68
IP67
IP66
IP65
IP54
IP40
IP69
flange
One piece, fast fit
fitting with nylon
swivel flange with
'O' ring.
FPA
IP68
IP67
IP66
IP65
IP54
IP40
IP69
nominal size (mm)
10
10
11
13
13
13
16
16
16
16
18
18
20
21
21
21
25
28
28
34
34
42
42
54
54
67
european (NW) sizes
7
7
8
10
10
10
12
12
12
12
14
14
17
23
29
29
36
36
48
48
56
straight external thread
One piece, fast fit, external threaded fitting.
Suitable for knockouts or threaded entries.
IP68
IP67
IP66
IP65
IP54
IP40
IP69
•
Specify black or grey (B = Black, G = Grey) eg. FPA16-M16B
•
The IP rating onto a UNEF threaded connector may be
dependent on the design of the connector
* Indicates parts made to order on request and
may be subject to MOQ and lead time
•
Available on request:
-
additional sizes, alternative threads
-
additional UNEF threads and combinations
-
all nylon UNEF threads
FPA90
90° elbow external thread
One piece, fast fit, external threaded 90 degree
elbow fitting. Suitable for knockouts.
IP68
IP67
IP66
IP65
IP54
IP40
IP69
Ext Metric
Ext PG
Ext NPT
Ext UNEF
Thread
Ext Flange
90 Degree Metric 90 Degree PG 90 Degree NPT
FPA10-M12
FPA10-PG7
FPA10-M12-90 FPA10-PG7-90
FPA10-M16
FPA10-PG9
FPA11-M12
FPA11-PG7
FPA11-M12-90
FPA13-M12
FPA13-PG7
FPA13-BU075
(
3
⁄
4
")
FPA13-M16-90 FPA13-PG9-90
FPA13-M16
FPA13-PG9
FPA13-M20
FPA13-PG11
FPA16-M16
FPA16-PG9
FPA16-038
FPA16-BU075
(
3
⁄
4
")
FPA16-FL
FPA16-M16-90 FPA16-PG9-90 FPA16-050-90
FPA16-M20
FPA16-PG11
FPA16-050
FPA16-BU100
(1")
FPA16-M16-90 FPA16-PG11-90
FPA16-PG13
FPA16-BU119
(1
3
⁄
16
")
FPA16-PG13-90
FPA16-PG16
FPA18-M20
FPA18-PG13
FPA18-M20-90
FPA20-M20
FPA20-M20-90
FPA21-M20
FPA21-PG13
FPA21-050
FPA21-BU100
(1")
FPA21-FL
FPA21-M20-90 FPA21-PG16-90 FPA21-050-90
FPA21-PG16
FPA21-BU119
(1
3
⁄
16
")
FPA21-BU138
(1
3
⁄
8
")
FPA25-M25
FPA25-M25-90
FPA28-M25
FPA28-PG21
FPA28-075
FPA28-BU138
(1
3
⁄
8
")
FPA28-FL
FPA28-M25-90 FPA28-PG21-90 FPA28-075-90
FPA28-M32
FPA28-PG29
FPA28-BU144
(1
7
⁄
16
")
FPA34-M32
FPA34-PG29
FPA34-100
FPA34-BU144
(1
7
⁄
16
")
FPA34-FL
FPA34-M32-90 FPA34-PG29-90 FPA34-100-90
FPA34-M40
FPA34-BU175
(1
3
⁄
4
")
FPA42-M40
FPA42-PG36
FPA42-125
FPA42-BU200
(2")
FPA42-FL
FPA42-M40-90 FPA42-PG36-90 FPA42-125-90
FPA42-M50
FPA42-150
FPA42-BU225
(2
1
⁄
4
")
FPA42-M50-90
FPA42-150-90
FPA54-M50
FPA54-PG42
FPA54-150
FPA54-BU200
(2")
FPA54-M50-90 FPA54-PG48-90 FPA54-150-90
FPA54-M63
FPA54-PG48
FPA54-200
FPA54-BU225
(2
1
⁄
4
")
FPA54-M63-90
FPA54-200-90
FPA67-M63
FPA67-PG48
FPA67-200
FPA67-M63-90 FPA67-PG48-90 FPA67-200-90
