Standards
Technical Drawing
REACh
BS EN IEC 61386
Standards
cable gland
One piece, fast fit, swivel, nickel plated brass
external threaded cable gland fitting. Suitable
for knockouts or threaded entries.
cable gland
One piece, fast fit, swivel, 90 degree
elbow, nickel plated brass external
threaded cable gland fitting. Suitable
for knockouts or threaded entries.
cable gland
One piece, fast fit, swivel, 45 degree
elbow, nickel plated brass external
threaded cable gland fitting. Suitable
for knockouts or threaded entries.
FPA
FPA90
FPA45
IP68
IP67
IP66
IP65
IP54
IP40
IP69
IP68
IP67
IP66
IP65
IP54
IP40
IP69
IP68
IP67
IP66
IP65
IP54
IP40
IP69
•
1 part fast fit
•
IP rating:
of conduit & fitting: IP66
of cable gland: IP68 (10 bar)+IP69
•
Vibration and shock tested to EN61373 Cat 2
•
Tamper resistant
•
Can be removed using a screwdriver
•
All round teeth give high pull off strength 70kg with FPAH21
•
Both 90˚ and 45˚ elbows incorporate swept bore to facilitate
cable installation and protect cables when installed
•
Suitable for fine and coarse pitch conduits
•
Temperature range:
conduit fitting: -50˚C to +135˚C
cable gland: -40˚C to +100˚C static
-20˚C to +100˚C dynamic
•
Low Fire Hazard (LFH), see page 102
•
Halogen, sulphur and phosphorus free
•
Refer to accessories for clamping range page 87
properties
OD mm
nominal size (mm)
NPB Metric
FPA16-BM20-CG-45
FPA21-BM20-CG-45
FPA28-BM25-CG-45
FPA34-BM32-CG-45
FPA42-BM40-CG-45
FPA54-BM50-CG-45*
NPB Metric
FPA13-BM16-CG-90
FPA16-BM16-CG-90
FPA16-BM20-CG-90
FPA21-BM20-CG-90
FPA28-BM25-CG-90
FPA34-BM32-CG-90
FPA42-BM40-CG-90
FPA54-BM50-CG-90*
NPB Metric
FPA13-BM16-CG
FPA16-BM16-CG
FPA16-BM20-CG
FPA21-BM20-CG
FPA28-BM25-CG
FPA34-BM32-CG
FPA42-BM40-CG
FPA54-BM50-CG*
NPB PG
FPA16-BPG11-CG*
FPA16-BPG16-CG*
FPA21-BPG16-CG*
FPA28-BPG21-CG*
FPA34-BPG29-CG*
FPA42-BPG36-CG*
european (NW) sizes
10
10
11
13
13
13
16
16
16
16
18
18
20
21
21
21
25
28
28
34
34
42
42
54
54
67
7
7
8
10
10
10
12
12
12
12
14
14
17
17
17
23
23
29
29
36
36
48
48
56
10.0
11.5
13.0
15.8
18.5
20.0
21.2
25.0
28.5
34.5
42.5
54.5
67.0
