NON-METALLIC
CONDUIT & FITTINGS
non-metallic conduit and fittings
Ordering Notes
FPAS FPAL FPAH
• High mechanical strength
• High impact resistance
• Temperature range -40˚C to +120˚C
• UL recognised
• Low Fire Hazard (LFH), see page 102
• UL 94 V2 flame retardancy
• Halogen, sulphur and phosphorus
free
• UV resistant
• Abrasion resistant
• Highly resistant to solvents and oils
Construction: Heavy weight, flame
retardant, nylon (PA6) corrugated
flexible conduit. Colour black.
Typical Applications: All types of
machinery and public buildings
where high mechanical strength
required.
FPAH13 50 13.0 9.0 35
FPAH16 50 15.8 11.5 45
FPAH21 50 21.2 15.5 55
FPAH28 50 28.5 21.3 60
FPAH34 25 34.5 27.6 70
FPAH42 25 42.5 34.6 80
FPAH54 25 54.5 46.0 90
outside dia (mm)inside dia (mm)min inside bendradius (mm) part numberreel length (m)
FPAH
• Highly flexible and high fatigue life
• High impact strength and recovers
if crushed
• Temperature range -40˚C to +120˚C
(-20˚C to +100˚C for moving
applications)
• UL recognised
• Highly resistant to solvents and oils
• Self extinguishing
• Halogen, sulphur and phosphorus
free
Construction: Light weight nylon
(PA6) corrugated flexible conduit.
Colour black or grey (RAL 7031).
Typical Applications: Machines
where lower mechanical protection
is required and buildings.
• Highly flexible and high fatigue life
• High impact strength and recovers
if crushed
• Temperature range -40˚C to +120˚C
(-20˚C to +100˚C for moving
applications)
• Lloyd’s Register Type Approval
• UL listed / UL recognised
• Low Fire Hazard (LFH), see page 102
• UL 94 V2 flame retardancy
• Halogen, sulphur and phosphorus
free
• UV resistant (black)
• Abrasion resistant
• Highly resistant to solvents and oils
• Slit version also available FPAS-S
please contact us
Construction: Standard weight,
flame retardant nylon (PA6)
corrugated flexible conduit.
Colour black or grey (RAL 7031).
Orange available on request.*
Typical Applications: All types
of machinery, public buildings.
outside dia (mm)inside dia (mm)min inside bendradius (mm) part numberreel length (m)
FPAS
outside dia (mm)inside dia (mm)min inside bendradius (mm) part numberreel length (m)
FPAL
FPAS10 50 10.0 6.3 15
FPAS11 50 11.5 8.2 20
FPAS13 25, 50 13.0 9.8 25
FPAS16 25, 50 15.8 11.8 35
FPAS18 50 18.5 14.2 40
FPAS20 10, 25, 50 20.0 14.8 45
FPAS21 10, 25, 50 21.2 16.7 45
FPAS25 10, 25, 50 25.0 19.1 50
FPAS28 10, 25, 50 28.5 22.8 50
FPAS28C* 50 28.5 21.6 50
FPAS34 25, 50 34.5 28.1 60
FPAS34F 50 34.5 28.8 60
FPAS42 10, 25, 50 42.5 35.5 70
FPAS54 10, 25, 50 54.5 47.2 80
FPAS67 10 67.2 56.3 130
FPAL10 50 10.0 6.5 15
FPAL11 50 11.5 8.4 20
FPAL13 50 13.0 10.0 25
FPAL16 50 15.8 12.0 35
FPAL18 50 18.5 14.2 35
FPAL20 50 20.0 15.0 40
FPAL21 50 21.2 16.9 40
FPAL25 50 25.0 19.3 45
FPAL28 50 28.5 23.0 45
FPAL34 25, 50 34.5 28.3 55
FPAL42 25 42.5 35.7 65
FPAL54 25 54.5 47.4 80
FPAL67 10 67.2 56.5 110
pitch nominal size (mm) european (NW) sizes
7 10 F
8 11 F
10 13 F
12 16 F
14 18 F
20 C
17 21 F
21 C
25 C
23 28 F
28 C
29 34 C
29 34 F
36 42 C
48 54 C
56 67 C
F = fine pitch C = coarse pitch NOTE: Other reel lengths are available upon request
Non-metallic systems are typically lighter, easier to work with and more cost effective to install.
With advances in material technologies non-metallic systems can provide an alternative solution
where typically only metal systems had been considered previously.
rey (B = Black, G = Grey)
and reel length eg: FPAS21B-50M for a Black 50m reel
• Some reel lengths are MTO in grey
• See cutting tool page 89
* Indicates parts made to order on request and
may be subject to MOQ and lead time
• Available on request:
- longer lengths and bulk
packaging
- cut lengths and assemblies
- other colours
- full copies of independent test
results confirming LFH properties
- conduit with pre-installed
draw wire
- fine pitch 34mm sizes
- Contractor Packs available
see page 90 & 91
