LTP, LTPAS
,
LTPHC, LTPUL
& LTPLFH
galvanised steel,
plastic coated liquid tight
LTP /
LTPAS
LTPUL
LTPHC
LTPLFH
Construction:
Galvanised steel, helically
wound, flexible steel conduit including
copper bonding strip (up to 40mm) with
smooth pvc cover. Colour black.
Typical Applications:
As for LTP but where
UL listing or CSA approval is required.
Special Characteristics:
UL listed and
CSA approved.
Construction:
Galvanised steel, helically
wound, flexible conduit with smooth oil
resistant and high temperature pvc cover.
Colour black. Grey or orange on request.
Typical Applications:
Machine tools or
outdoor installations where liquid tight is a
requirement.
Special Characteristics:
Oil resistant and
self extinguishing.
LTPAS
version as above but with
anti-static performance coating (only
available in black).
Construction:
Galvanised steel, helically
wound, flexible conduit with smooth oil
resistant Low Fire Hazard (LFH) cover.
Colour black.
Typical Applications:
Rail applications.
Special Characteristics:
As per LTP but
where Extra Low Fire Hazard performance
is required.
Construction:
Galvanised steel, helically
wound, flexible conduit with smooth
thermoplastic elastomer (TPE) cover.
Colour black.
Typical Applications:
Machine tools or
outdoor installations where low or high
temperature rating is required. ie. food
processing
Special Characteristics:
Wide
temperature range performance. Good
flexibility at low and high temperatures.
C
external thread
nickel plated brass
Multipart compression fitting
including elastomeric seal.
Can be used for knockout or
threaded entries as fitting
rotates until tightened.
IP68
IP67
IP66
IP65
IP54
IP40
IP69
I
I
I
I
I
I
I
metric thread
part number
for NPT
thread size
for PG
thread size
Note:
Stainless steel fittings
also available see page 67
When ordering PG or NPT
please see below.
outside dia (mm)
US trade size (“)
inside dia (mm)
min inside bend
radius (mm)
min inside bend
radius (mm)
min inside bend
radius (mm)
part number
part number
reel length (m)
reel length (m)
reel length (m)
LT P
LT PA S
min inside bend
radius (mm)
part number
reel length (m)
LT P H C
part number
LT P U L
LT P L F H
nominal size (mm)
10
10
12
16
16
20
25
32
40
50
63
min inside bend
radius (mm)
reel length (m)
part number
conduit
thread size
fitting type
LTP10-M12-C LTP16-PG13-C
or
LTP16-050-C
STANDARD
LOW FIRE
HAZARD
EXTRA
LOW FIRE
HAZARD
INHERENT
LOW FIRE
HAZARD
#
STANDARD
LOW FIRE
HAZARD
EXTRA
LOW FIRE
HAZARD
INHERENT
LOW FIRE
HAZARD
•
Add reel length eg: LTP20B-25M for a 25m reel
• For LTP specifycolour (B = Black, G = Grey)
* Indicates parts made to order on request and
may be subject to MOQ and lead time
+ Double interlock section
# PG & NPT threads not supplied with insulated throats
•
Available on request:
-
longer lengths and bulk packaging
-
cut lengths and assemblies
-
C-S with PG threads
-
other colours
-
internal thread fittings
LTP10-M12-C
LTP10-M16-C
LTP12-M16-C
LTP16-M16-C
LTP16-M20-C
LTP20-M20-C
LTP25-M25-C
LTP32-M32-C
LTP40-M40-C
LTP50-M50-C
LTP63-M63-C
PG7
PG9
PG11
PG13
PG16
PG21
PG29
PG36
PG42
PG48
050
050
075
100
125
150
200
1
⁄
4
11.8 7.0
LTP10B +
50 35
5
⁄
16
14.2 10.0
LTP12B
25, 50 40
3
⁄
8
17.8 12.6
LTP16B
10, 25, 50 45
1
⁄
2
21.1 16.0
LTP20B
10, 25, 50 65
3
⁄
4
26.4 21.0
LTP25B
10, 25, 50 100
1 33.1 26.5
LTP32B
10, 25, 50 135
1
1
⁄
4
41.8 35.4
LTP40B
10, 25 175
1
1
⁄
2
47.9 40.4
LTP50B +
10, 25 230
2 59.7 51.6
LTP63B +
10, 25 280
LTPHC12B +
25 40
LTPHC16B
25 45
LTPUL16B
25 50
LTPHC20B
25 65
LTPUL20B
25 90
LTPHC25B
25 100
LTPUL25B
25 110
LTPHC32B
25 135
LTPUL32B
10, 25 140
LTPHC40B
10 175
L
TPUL40B
15 180
LTPHC50B +
10 230
L
TPUL50B +
15 230
LTPHC63B* +
10 280
L
TPUL63B +
15 280
LTPLFH16B
25 60
LTPLFH20B
10, 25 100
LTPLFH25B
10, 25 130
LTPLFH32B
10
180
LTPAS16B*
25 45
LTPAS20B*
25 65
LTPAS25B*
25 100
LTPAS32B*
25 135
LTPAS40B*
10 175
LTPAS50B* +
10 230
LTPAS63B* +
10 280
(½")
(½")
(¾")
(1")
(1¼")
(1½")
(2")
