Standards
59
Technical Drawing
• High mechanical strength
• Highly flexible
• Inherently Low Fire Hazard (LFH)
• Fully compliant to LUL Std 1-085 (Cert No. 296)
• Temperature range -100˚C to +300˚C (FU)
-100˚C to +600˚C (SSU + SS fittings)
-100˚C to +400˚C (SSU + NPB fittings)
• IP rating: IP40
• SSU is highly corrosion resistant
• Nickel plated brass fittings
• Stainless steel (316) fittings
system properties
metric threadpart number plated steelpart numberstainless steelpart number
10
12
16
16
20
25
32
40
50
63
75
part number hole size (mm) metric threadpart number part number
S-SS
swivel external
thread stainless
steel
Two part fitting comprising
shell and body. The external
thread swivels about the
main body. Can be used with
threaded entries, or knockout
secured with a locknut.
IP68 IP67 IP66 IP65 IP54 IP40 IP69
P
plain hole connector
nickel plated brass
Two part fitting comprising
shell and body without thread.
The body is fitted through the
opposite side of the entry to
the conduit and acts as a
locking device also providing
a smooth entry bush.
IP68 IP67 IP66 IP65 54 40 IP69
F
fixed internal thread
nickel plated brass
Two part fitting comprising
shell and body with internal
thread which can be used
to connect with an
external thread.
IP68 IP67 IP66 IP65 54 40 IP69
FCC
plated steel P clip
with pvc liner and
secure stainless
steel P clips
P clip to support and secure
conduit.
90° elbow
internal and external
threaded nickel
plated brass elbow
90˚ elbow which can be
screwed onto external
threaded fittings to create a
90° elbow termination.
BS EN IEC 61386
Note: refer to conduit properties for applicable standards
SSU10-M12-S
SSU12-M16-S
SSU16-M16-S
SSU20-M20-S
SSU25-M25-S
SSU32-M32-S
BM90-PG7
BM90-16M
BM90-16M
BM90-20M
BM90-20M
BM90-25M
BM90-32M
BM90-40M
BM90-50M
FCC10 FCC10-SS*
FCC12 FCC12-SS*
FCC16 FCC16-SS
FCC16 FCC16-SS
FCC20 FCC20-SS
FCC25 FCC25-SS
FCC32 FCC32-SS
FCC40 FCC40-SS
FCC50 FCC50-SS*
FCC63
FCC75
9 FU10-P
12 FU12-P
16 FU16-P
20 FU20-P
25 FU25-P
32 FU32-P
40 FU40-P
51 FU50-P
61 FU63-P
75 FU75-P
FU16-M16-F
FU16-M20-F
FU20-M20-F
FU25-M25-F
FU32-M32-F
FU40-M40-F
FU50-M50-F
FU63-M63-F
REACh
